6ED1052-1FB00-0BA7

Artikelnummer

6ED1052-1FB00-0BA7

		LOGO!230RCE,LOGIC MODULE,DISPL. PU/I/O: 115V/230V/RELAY, 8 DI/4 DO, MEM. 400 BLOCKS, EXPANDABLE WITH EXTRA MODULES, 230V AC/DC, ETHERNET
Installation type/mounting
Mounting		on 35mm DIN rail, 6 spacing units wide
Supply voltage
115 V DC		Yes
230 V DC		Yes
permissible range, lower limit (DC)		100 V
permissible range, upper limit (DC)		253 V
115 V AC		Yes
230 V AC		Yes
Time of day
Time switching clocks
● Number		333
● Power reserve		480 h
Digital inputs
Number of digital inputs		8
Digital outputs
Number of digital outputs		4; Relays
short-circuit protection		No; external fusing necessary
Relay outputs
Switching capacity of contacts
— with inductive load, max.		3 A
— with resistive load, max.		10 A
EMC
Emission of radio interference acc. to EN 55 011
● Limit class B, for use in residential areas		Yes; Radio interference suppression according to EN55011, Limit Value Class B
Degree and class of protection
Degree of protection to EN 60529
● IP20		Yes
Standards, approvals, certificates
CSA approval		Yes
UL approval		Yes
FM approval		Yes
Developed in accordance with IEC 61131		Yes
according to VDE 0631		Yes
Marine approval
● Marine approval		Yes
Ambient conditions
Operating temperature
● Min.		0 °C
● max.		55 °C
Dimensions
Width		107 mm
Height		90 mm
Depth		55 mm
last modified:		25.09.2014

6ED1052-1FB00-0BA7 LOGO! 230RCE, 8DI/4DO, 400 BLOCKS
